What is Grade 1035?

Grade 1035 is a medium carbon steel. Heat treatment improves its hardness and strength. This 1035 tube has a balance of strength and machinability. With 0.32-0.38% carbon, it reacts well to quench and temper heat treatment. It keeps reasonable weldability if you use the right preheat steps. This grade is common when you need moderate strength and good wear resistance. It has less carbon than 1040 or 1045 grades.

ASTM A519 Grade 1035 Tube Specifications

Technical specifications for ASTM A519 Grade 1035 seamless mechanical tubing contain standard, grade, dimensions, and conditions offered:

Feature Detail
Specification ASTM A519 / ASME SA519
Product Name A519 Mechanical Tubing, A519 Steel Tube
Size Range 1/4" OD to 24" OD
Wall Thickness Schedule 10 through XXS
Manufacturing ASTM A519 Seamless Tube, Drawn-Over-Mandrel (DOM)
Finish Hot-Finished (HF), Cold-Drawn (CD), Annealed, Normalized
Grade 1035

ASTM A519 Grade 1035 Tube Chemical Composition

The table given below consists of the chemical composition of SAE 1035 steel as per ASTM A519.

Carbon Silicon Manganese Phosphorous Sulphur Molybdenum Nickel Chromium Copper Others
0.32-0.37 – 0.60-0.90 0.04 0.05 – – – – –

ASTM A519 Grade 1035 Tube Mechanical Properties

Mechanical properties of 1035 steel tube show its high tensile and yield strength.

Yield Strength Tensile Strength Elongation A5 min
MPa min ksi min MPa min MPa min ksi min Percentage
    448 – 65 20

ASTM A519 Grade 1035 Tube Equivalent Grades

Grade 1035 equivalents across international standards include UNS G10350 and DIN 1.0501, among others.

DIN EN BS NFA ASTM ASME
DIN 17204 Grade C35 EN C35E Grade 10083-2 NFA A 49-311 Grade TU XC 35 ASTM A519 Grade 1035 ASME SA 519 Grade 1035 –

Applications

The 1035 steel tube serves 5 major industrial applications:

Structural Applications

Load-bearing frames, supports, and structural members benefit from the combination of strength and toughness that 1035 tubing provides.

Machinery Parts

Shafts and couplings use 1035 tube because the metal responds to heat treatment. It has good machinability. Spindles are another use.

Fabrication Projects

Welded assemblies use 1035 tubing. You must use proper preheat procedures. It is used for fabricated structures needing moderate strength.

Pipelines

Industrial fluid transfer lines use the durability of 1035 seamless tubing. Apart from this, it is used for process piping in moderate pressure setups.

Automotive Industry

Axle tubes, drive shaft components, and structural automotive parts use 1035 tubing for its balance of strength, formability, and weldability.
